Casing:
1,5 mm thick; welded monobloc structure; possibility to install plinths.
Internal plate:
2,5 mm thick galvanised steel sheet (Sendzimir), non-adjustable depth.
Cable entry flange:
1,5 mm steel sheet; it consists in 2 parts, with neoprene cable-tie gasket.
Solid door:
1,8 mm thick steel sheet; polyurethane sealing gasket; 20x20 mm pre-drilled tubular frame. 100° standard opening with reversible right hinges. Standard central locking systems with double-comb tool insert and 4 anchor points. Other configurations are available.
Earthing:
M6 pins to be welded on structure and doors.
Painting:
Thermosetting powders.
Material:
1,5/1,8 mm thick carbon steel sheet.
Standard colours: RAL7035 textured - Plinth: RAL7009 textured
IP66 for internal use (for external use contact our technical department at ufficiotecnico@zanardo.com)
IK10 impact resistance degree according to IEC EN 62208
NEMA12
Technical data subject to change without notice
