Casing:
1,5 mm thick steel; welded monobloc structure.
Internal Plate:
2 mm thick galvanised steel sheet (Sendzimir), not adjustable.
Cable Entry:
Flange both on top and bottom sections with gasket.
Solid door:
1,5 mm thickness; polyurethane sealing gasket; Pre-drilled internal supports for elements mounting (from H606); pvc locking systems with 3 mm double-comb tool insert, other configurations are available. 120° standard opening with reversible left hinges.
Earthing:
M6 pins to be welded on structure and doors.
Painting:
Thermosetting powders
Material:
1,5 mm thick carbon steel sheet
Standard Colours:
RAL7035 textured
IP66 for internal use (for external use contact our technical department ufficiotecnico@zanardo.com)
IK10 impact resistance degree for IEC EN 62208
Technical data subject to change without notice
